Protection Waterproof Heat Shrink End Cap for cable connection termination

Availability:
Quantity:
Inquire Add to Basket

Heat shrinkable cable end caps

The inner surface of the end cover has a layer of helically coated hot melt adhesive, which still retains its flexibility after recovery. It is recommended for use in open air and underground distribution cables with PVC, lead or crosslinked polyethylene sheaths.

Made of cross-linked polyolefin.

-RoHS compliant
-Hot melt adhesive lining provides permanent seal on irregular cable sheaths.
-Excellent resistance to weathering, moisture, contamination and adverse environmental conditions.
- operating temperature: -55ºC~110ºC
-Shrink temperature: 120ºC
-Standard colors: black
Technical Data:


Test Properties		Test MethodTypical Data
Tensile StrengthASTM D 2671≥11Mpa
Elongation at breakASTM D 2671≥400%
DensityASTM D 7921.05g/cbm
Elongation after heat ageing150°C, 168h≥300%
Dielectric StrengthIEC 243≥15KV/mm
Volume ResistivityIEC 93≥10^14Ω.cm


Previous:
Next:
cable cap heat shrink cap end cap cap cable accessory pe silicone
